VES U/M 12L ICEBOX 12 Volt DC

VES U/M ICEBOX – High-Efficiency Undermount DC Air Conditioner

The VES U/M ICEBOX is a high-performance undermount DC air conditioning system, designed for tight-space installations in vans, RVs, boats, and off-grid setups. Built with the same premium components as the VES ICEBOX, this undermount AC unit features a remote-mounted compressor, allowing for flexible installation inside or outsideyour vehicle or vessel.

Why Choose the VES U/M ICEBOX Undermount AC?

✔️ Undermount Design – Perfect for applications where space is limited and a traditional rooftop or wall-mounted unit won’t fit.
✔️ Compact & Modular – The multi-piece design allows installation in areas where standard AC systems can’t go.
✔️ Rugged Durability – The compressor is heavily protected in 304 stainless steel for impact resistance.
✔️ Easy Installation – Top- or bottom-mounted brackets make placement flexible, and electronics can be positioned near your power system.
✔️ Multiple Cable Length Options – Choose the best fit for your installation needs:

• 12V System: 5-foot or 7-foot cable
• 24V System: 5-foot, 7-foot, or 10-foot cable
• 48V System: 5-foot, 7-foot, or 10-foot cable

Powerful Cooling with Flexible Mounting Options

The ICEBOX evaporator is designed for optimal airflow and cooling efficiency:

• Multi-position mounting – Ceiling, floor, or cabinet installation options.
• Rotatable blower – Direct air in nearly any direction, including downward for high-mounted cabinets.
• Better air circulation – Mounting the evaporator high makes vent routing easier and improves cooling power.

Because of its multi-piece undermount design, the VES U/M ICEBOX fits into tight spaces where traditional rooftop or bulky AC units can’t be installed. Whether you need 12V, 24V, or 48V undermount air conditioning, this system is the ultimate cooling solution for off-grid applications.

The Best Undermount Air Conditioner for Vans, RVs & Marine Use

At Cruise N Comfort USA, we specialize in high-efficiency, battery-powered undermount AC systems that outperform imported alternatives. The VES U/M ICEBOX delivers reliable cooling without sacrificing space or efficiency.

Refrigerant Compatibility: Supports both R134a and R513a refrigerants.

 Refrigerant hose kits (custom lengths and pre-sized options) are available in the Upgrades section.

 IN STOCK – Order Today!

Technical Specifications:

Voltage Operating Range:

 VES U/M ICEBOX 12L – 10-15V DC
 VES U/M ICEBOX 24L – 20-31V DC
 VES U/M ICEBOX 48L – 40-62V DC

Current Consumption:

⚡ VES U/M ICEBOX 12L – 38-55A DC
⚡ VES U/M ICEBOX 24L – 25-33A DC
⚡ VES U/M ICEBOX 48L – 8-16A DC

Cooling Capacity:

❄️ VES U/M ICEBOX 12L – 10,000 BTU
❄️ VES U/M ICEBOX 24L – 11,000 BTU
❄️ VES U/M ICEBOX 48L – 12,000 BTU

Weight:

• Evaporator – 17.8 lbs
• Compressor – 29 lbs
• Controller – 8.7 lbs
• Single Fan Condenser – 7.75 lbs

 Warranty: 1 Year
